MODEL

OUTPUT

SIZE (mm)

WEIGHT (kg)

VOLTAGE

CURRENT

BK 1000S - 12

12 V

83.3 A

L : 283 mm
W : 160 mm
H : 65 mm

3.12 kg

BK 1000S - 15

15 V

66.6 A

BK 1000S - 24

24 V

41.6 A

BK 1000S - 28

28 V

35.7 A

BK 1000S - 36

36 V

27.7 A

BK 1000S - 48

48 V

20.8 A

INPUT VOLTAGE (Vac)

95 - 130 Vac or 195 - 265 Vac

FREQUENCY (Hz)

50 / 60 Hz

EFFICIENCY (%)

81% minimum ( base on 12V )

INRUSH CURRENT (A)

30A typ (AC IN 110V, Full load),
60A typ (AC IN 220V, Full load) at cold start

EMC / EMI STANDARD

KN22, KN61000-4-2, KN61000-4-3 KN61000-4-4,
KN61000-4-5, KN61000-4-6 KN61000-4-11

SAFETY STANDARD

K61347-1, K61347-2-13, K62384

MODEL

REGULATION
LINE (mV)

REGULATION
LOAD (mV)

RIPPLE (mV)

RIPPLE &
NOISE (mV)

BK 1000S - 12

60 max

120 max

120 max

170 max

BK 1000S - 15

75 max

150 max

150 max

200 max

BK 1000S - 24

120 max

240 max

240 max

290 max

BK 1000S - 28

140 max

280 max

280 max

330 max

BK 1000S - 36

180 max

360 max

360 max

410 max

BK 1000S - 48

240 max

480 max

480 max

530 max

OVER CURRENT PROTECTION

Works at over 110% of rating and recovers automatically

OVER VOLTAGE PROTECTION

Works at 115~140% of rating

START ON TIME (S)

1 max (AC IN 110V / 220V, Full load)

HOLD UP TIME (mS)

10 typ (AC IN 110V / 220V, Full load)

ADJUSTABLE RANGE

OUTPUT DC ± 10 %

ENVIRONMENT

Operating temperature and humidity

-10 ~ +80 ℃, 20 ~ 90%,
RH (Non condensing)

Storage temperature and humidity

-20 ~ +85 ℃, 20 ~ 90%,
RH (Non condensing)

Vibration

10 ~ 55Hz at 1G 3minute periods,
30minute along X, Y and Z axis,
at no Operating

Impact (in package)

Less than 10G

ELECTRICALLY
ISOLATED

Input - Output

AC 3,000V 1minute, DC 500V 100MΩ
(At room temperature & Humidity)

Input - Case,FG

AC 1,500V 1minute, DC 500V 100MΩ
(At room temperature & Humidity)

Output - Case

AC 500V 1minute, DC 500V 100MΩ
(At room temperature & Humidity)

상호

파워뱅크(주)

모델

BK 1000S

제조년월

2025.

제조자

파워뱅크(주)

제조국가

한국

인증번호

HH11656-13007A
KCC-REM-pbk-BK1000S-48
