MODEL

OUTPUT

SIZE (mm)

WEIGHT (kg)

VOLTAGE

CURRENT

BK 8000XG - 48

48 V

166 A

L : 333 mm
W : 669 mm
H : 164 mm

31 kg

BK 8000XG - 72

72 V

111 A

BK 8000XG - 100

100 V

80 A

BK 8000XG - 200

200 V

40 A

BK 8000XG - 260

260 V

30 A

BK 8000XG - 300

300 V

26 A

BK 8000XG - 360

360 V

22 A

BK 8000XG - 440

440 V

18 A

BK 8000XG - 600

600 V

13 A

BK 8000XG - 800

800 V

10 A

INPUT VOLTAGE (Vac)

95 - 130 Vac or 195 - 265 Vac

FREQUENCY (Hz)

50 / 60 Hz

EFFICIENCY (%)

80% minimum ( base on 48V )

INRUSH CURRENT (A)

30A typ (AC IN 110V, Full load),
60A typ (AC IN 220V, Full load) at cold start

EMC / EMI STANDARD

KN22, KN61000-4-2, KN61000-4-3, KN61000-4-4, KN61000-4-5, KN61000-4-6, KN61000-4-11

SAFETY STANDARD

K61347-1, K61347-2-13, K62384

MODEL

REGULATION
LINE (mV)

REGULATION
LOAD (mV)

RIPPLE (mV)

RIPPLE &
NOISE (mV)

BK 8000XG - 48

240 max

480 max

480 max

530 max

BK 8000XG - 72

360 max

720 max

720 max

770 max

BK 8000XG - 100

500 max

1000 max

1000 max

1050 max

BK 8000XG - 200

1000 max

2000 max

2000 max

2050 max

BK 8000XG - 260

1300 max

2600 max

2600 max

2650 max

BK 8000XG - 300

1500 max

3000 max

3000 max

3050 max

BK 8000XG - 360

1800 max

3600 max

3600 max

3650 max

BK 8000XG - 440

2200 max

4400 max

4400 max

4450 max

BK 8000XG - 600

3000 max

6000 max

6000 max

6050 max

BK 8000XG - 800

4000 max

8000 max

8000 max

8050 max

OVER CURRENT PROTECTION

Works at over 110% of rating and recovers automatically

OVER VOLTAGE PROTECTION

Works at 115~140% of rating

START ON TIME (S)

1 max (AC IN 110V / 220V, Full load)

HOLD UP TIME (mS)

10 typ (AC IN 110V / 220V, Full load)

ADJUSTABLE RANGE

OUTPUT DC ± 10 %

ENVIRONMENT

Operating temperature and humidity

-10 ~ +80 ℃, 20 ~ 90%,
RH (Non condensing)

Storage temperature and humidity

-20 ~ +85 ℃, 20 ~ 90%,
RH (Non condensing)

Vibration

10 ~ 55Hz at 1G 3minute periods,
30minute along X, Y and Z axis,
at no Operating

Impact (in package)

Less than 10G

ELECTRICALLY
ISOLATED

Input - Output

AC 1,500V 1minute, DC 500V 100MΩ
(At room temperature & Humidity)

Input - Case,FG

AC 1,500V 1minute, DC 500V 100MΩ
(At room temperature & Humidity)

Output - Case

AC 500V 1minute, DC 500V 100MΩ
(At room temperature & Humidity)

상호

파워뱅크(주)

모델

BK 8000XG

제조년월

2020.

제조자

파워뱅크(주)

제조국가

한국
